Customer Requirements:
*The machined workpiece is a motor shaft with 360-490 length, and about 3-6kg weight;
*Machining cycle time of the production line is within 140s, i.e., one production line performs one finished product that takes even 70s;
*Ensure stable, safe and reliable working.
Application Effect:
*Its storage shelf can arrange MS100L 180 rods once to meet 3-hour continuous machining, and it is not regulated during changing rods with the same diameter and different specifications, and is slightly done during changing rods with different diameter;
*The stacked rack is driven by the motor, the splitting wheel runs and carries the blank to the robot loading position to transport materials to the robot. When the sensor have not inspected the material within one minute, the motor stops rotation, and sends guard signals to remind the workers to charge into the stock bin. The whole robot setting has multiple guard, safe and stable;
* According to 26 days per month, 2 shifts to 16 hours per day, the counted machining time of MS100L part, a finished product formed in 65s and more than 18000PS per month, the planned production program can meet the customer requirements.
